iUAP-AC-LITE

iUAP-AC-LITE

AC1200 Wave 2 Gigabit Access Point
  • MU-MIMO for high throughput
  • MUp to 1167 Mbps dual-band data rate
  • M24V0.5A Passive PoE or IEEE 802.3af/at PoE power supply
  • MRange of up to 150 meters
The IEEE 802.11ac Wave 2-compliant iUAP-AC-LITE is a gigabit dual-band ceiling access point. It offers a concurrent data rate as high as of 1167 Mbps. Powered by MU-MIMO technology, a single iUAP-AC-LITE can simultaneously communicate with multiple clients, greatly improving the throughput and bettering user experience. The built-in omni-directional antennas optimize signal radiating directions, broadening the wireless coverage of a single AP. iUAP-AC-LITE can be powered by PoE sourcing equipment that compliant with IEEE 802.3af/at. With its ceiling installation design and sleek appearance, it simplifies wireless networking for enterprises, hotels and other public indoor spaces.

Gigabit internet connections for ultra-fast experience

Up to 1167 Mbps dual-band data rate, and the Gigabit Ethernet port offers you ultra-fast internet connections.

IEEE 802.11ac Wave 2 and MU-MIMO

Compliant with IEEE 802.11ac Wave 2 and powered by MU-MIMO technology, a single iUAP-AC-LITE can communicate with multiple wireless clients simultaneously, leading to higher throughput.

2.4 GHz and 5 GHz bands for more connected clients

The dual-band wireless design allows clients that support 2.4 GHz and/or 5 GHz bands to connect to the AP at the same time, tripling the quantity of connected clients of traditional single-band AP.

Built-in omni-directional antennas

With the optimized built-in high-gain omni-directional antennas, iUAP-AC-LITE outperforms in radiating wireless signals, and greatly broadens its wireless coverage.

Built-in RF optimization

iUAP-AC-LITE supports RF optimization technology and integrates with various algorithms for interference mitigation. Features include multi-user fairness, interference filtering, speed optimization, and signal strength guarantee.

VLAN tagging for SSID

iUAP-AC-LITE allows you to set multiple SSIDs, and the IEEE 802.11q VLAN-compliant feature enables you to add VLAN tags for SSIDs, thus protecting the security of your network.

Standard PoE sourcing and DC power supply for easy deployment

iUAP-AC-LITE can be powered by PoE sourcing equipment that compliant with IEEE 802.3af/at and 24V0.5A Passive PoE

Centralized management

The iUniFi Controller makes it easy to manage and monitor the whole iUniFi devices in a real-time manner and cloud services enable a remote and secure access free from the restrictions of device location.

  • MU-MIMO for high throughput
  • MUp to 1167 Mbps dual-band data rate
  • M24V0.5A Passive PoE or IEEE 802.3af/at PoE power supply
  • MRange of up to 150 meters
Product Information
Model iUAP-AC-LITE
Appearance Ceiling
Dimensions 176*176*43.5mm
Hardware Specifications
Frequency band 2.4 GHz, 5 GHz
Wireless standards IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
2.4 GHz data rate 1 - 300 Mbps
5 GHz data rate 6 - 867 Mbps
Ethernet port 1*10/100/1000 Base-TX port
Button 1*Reset
LED indicator 1*Power
Max. power consumption Full-load 11.5W
Power supply standard IEEE 802.3af/at&24V0.5A Passive PoE
Antenna gain 2*4 dBi
2.4 GHz Max. output power 26+/- 1.5 dBm
5 GHz Max. output power 26 +/-1.5 dBm
802.11b RX sensitivity -93 dBm
2.4 GHz 802.11n (MCS7) RX sensitivity -72 dBm
5 GHz 802.11a RX sensitivity -93 dBm
5 GHz 802.11n (MCS7) RX sensitivity -74 dBm
Software Specification
Operating modes AP, Client + AP
Hide SSID Supported
Max. No. of SSID 2.4 GHz:8
5 GHz:4
Max. connected clients 2.4 GHz:128
5 GHz:256
WEP Supported
WPA-PSK AES/TKIP
WPA2-PSK AES/TKIP
WPA Supported
WPA2 Supported
Access control MAC address-based
Adjustable power transmit Supported
Frequency analysis Supported
AP isolation Supported
Connected clients control Supported
RSSI threshold Supported
Transmission Power Adjustable power by 1dBm
WMM Supported
VLAN tagging for SSID Supported
LED indicator control Supported
Diagnostics tool Ping, Traceroute
Scheduled reboot Supported
Reboot at specified interval Supported
Management Web UI
System logs Supported
Firmware upgrade Local and AC upgrade
Reboot Local and AC reboot
Reset Local and AC reset
Backup configuration Supported
Restore configuration Supported
Operating Environment
Default login IP address 192.168.0.254
Default user name admin
Default password admin
Operating temperature -10℃ - 45℃
Operating humidity (10%-90%) RH, non-condensing
Storage temperature -30℃ - 70℃
Storage humidity (10%-90%) RH, non-condensing
