W66AP

W66AP

AC1750 Wave2 Gigabit Access Point
  • 3×3 MU-MIMO design for wider coverage and higher capacity.
  • Gigabit internet connection for ultra-fast experience.
  • Up to 1750 Mbps dual-band data rate.
  • Centralized management by all IP-COM ACs and enterprise routers.
Compliant with IEEE 802.11ac Wave2, W66AP is a gigabit dual-band ceiling access point. Powered by 3×3 MU-MIMO technology, a single W66AP can simultaneously communicate with multiple clients, greatly improving throughput and enhancing user experience. W66AP offers reliable high-performance wireless solutions for indoor space with a mass of connected users, such as restaurants, conference rooms and classrooms.

3×3 MU-MIMO design

The 3×3 MU-MIMO design generates a concurrent rate of 1750 Mbps, providing a better performance.

IEEE 802.11ac Wave2

Powered by MU-MIMO technology, a single W66AP can communicate with multiple wireless clients at one time, letting you enjoy higher throughput and better experience.

Dual-band for more connected clients

W66AP allows clients that support either 2.4 GHz or 5 GHz band, or both to connect to it at the same time, tripling the quantity of connected clients of traditional single-band AP.

Gigabit internet connection for ultra-fast experience

Up to 1750 Mbps dual-band data rate and the Gigabit Ethernet port offer you ultra-fast internet connections.

Built-in RF for intelligent optimization

Featuring various anti-interference algorithms, the built-in RF enables W66AP to evenly allocate bandwidth resources for multiple users, filter interference, and optimize date rate, offering you a guaranteed signal strength and reliable wireless experience.

VLAN tagging for SSID

W66AP allows you to set multiple SSIDs and add VLAN tags for SSIDs, thus protecting your network.

Standard PoE sourcing and DC power supply for easy deployment

You can use an IEEE 802.3at-compliant PoE sourcing equipment, or a 12V DC power adapter to power on W66AP.

Centralized management

You are allowed to configure and manage multiple W66AP in a centralized manner through all IP-COM access controllers (AC) and enterprise routers that include AC functionality, and enjoy simple management, configuration and monitoring of all access points.

  • 3×3 MU-MIMO design for wider coverage and higher capacity.
  • Gigabit internet connection for ultra-fast experience.
  • Up to 1750 Mbps dual-band data rate.
  • Centralized management by all IP-COM ACs and enterprise routers.
Product Information
Model W66AP
Appearance Ceiling
Dimensions 178 mm * 178 mm * 38 mm
Hardware Specifications
Frequency band 2.400 – 2.4835 GHz, 5.150 – 5.250 GHz
Wireless standards IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac
2.4 GHz data rate 1 - 450 Mbps
5 GHz data rate 6 - 1299 Mbps
Ethernet port 1*10/100/1000 Base-TX RJ45 port
Button 1*Reset
LED indicator 1*SYS,1*2.4 GHz,1*5 GHz
Max. power consumption Full-load 13.5W
Power supply standard IEEE 802.3at PoE, DC 12V 1.5A
Software Specifications
Operating modes AP, Client+AP
Hide SSID Supported
Max. No. of SSID "2.4 GHz: 8 5 GHz: 4"
Max. connected clients "2.4 GHz: >200 5 GHz: >200"
WEP Supported
WPA-PSK AES/TKIP
WPA2-PSK AES/TKIP
WPA Supported
WPA2 Supported
Access control MAC address-based
Adjustable power transmit Supported
Frequency analysis Supported
AP isolation Supported
Connected clients control Supported
RSSI threshold Supported
WMM Supported
VLAN tagging for SSID Supported
Antenna gain 6*4 dBi
2.4 GHz Max. output power 23 +/- 1.5 dBm
5 GHz Max. output power 23 +/- 1.5 dBm
802.11b RX sensitivity -93 dBm
2.4 GHz 802.11n (MCS7) RX sensitivity -74 dBm
5 GHz 802.11a RX sensitivity -97 dBm
5 GHz 802.11n (MCS7) RX sensitivity -78 dBm
Prefer 5 GHz Supported
LED indicator control Supported
Diagnostics tool Ping, Traceroute
Scheduled reboot Supported
Reboot at specified interval Supported
Management Web UI
System logs Supported
Firmware upgrade Local and AC upgrade
Reboot Local and AC reboot
Reset Local and AC reset
Backup configuration Supported
Restore configuration Supported
Working Environment
Default login IP address 192.168.0.254
Default user name admin
Default password admin
Operating temperature -10 ℃ - 45 ℃
Operating humidity (10% - 90%) RH, non-condensing
Storage temperature -30 ℃ - 70 ℃
Storage humidity (10% - 90%) RH, non-condensing
Certificates
Certificates CE\FCC\RoHS
