G3350F G3350F G3350F G3350F

G3350F

48GE+2SFP Cloud Managed Switch
  • Compliance with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z, and IEEE 802.1p/q/w/d/s standards
  • 48 x 10/100/1000 Base-T Ethernet ports; 2 x 100/1000 Base-X SFP ports
  • 16K MAC address and MAC address automatic learning
  • 12 Mb large buffer
  • Switching capacity: 100 Gbps
  • VLAN, IGMP, QoS, ACL, DHCP Snooping and Telnet supported
  • CloudFi App management and local visualization management supported
G3350F is a 48GE+2SFP layer-2 cloud managed switch designed by IP-COM for such scenarios with dense network as office network of SMBs and computer room network of campuses. With 48*10/100/1000 Base-T Ethernet ports and 2*1000 Base-X SFP ports, the switch supports cloud platform management, remote App management and local visualization, realizing easy and efficient network maintenance at a lower cost.

App remote management

Scan the QR code to add the switch to the CloudFi App for remote management. Then, you can use such functions as VLAN configuration, DHCP snooping and loop guard on the App, making operation and maintenance easier.

Dual-image Backup

The switch supports dual-image backup, ensuring stable operation and improving stability.

SFP port uplink

2 SFP uplink ports are offered to ensure a smooth long-distance cascading.

Topology Visualization

The system can generate a network topology automatically. It supports IP camera discovery based on ONVIF protocol and network device discovery based on LLDP, as well as online/offline status detection for all devices in the network, which improves the LAN operation and maintenance efficiency and also reduces the maintenance cost.

  • Compliance with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z, and IEEE 802.1p/q/w/d/s standards
  • 48 x 10/100/1000 Base-T Ethernet ports; 2 x 100/1000 Base-X SFP ports
  • 16K MAC address and MAC address automatic learning
  • 12 Mb large buffer
  • Switching capacity: 100 Gbps
  • VLAN, IGMP, QoS, ACL, DHCP Snooping and Telnet supported
  • CloudFi App management and local visualization management supported
Hardware specifications
Network standards IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.1p, IEEE 802.1q, IEEE 802.1w, IEEE 802.1d, IEEE 802.1s
LED indicators One Link/Act LED indicator for each port
One Power LED indicator
One SYS LED indicator
Fixed ports 48 x 10/100/1000Base-T Ethernet port
2 x 1000Base-X SFP slot
Lightning protection Port: 6 kV
Power supply: 6 kV
Forwarding mode Store-and-forward
Switching capacity 100 Gbps
Packet forwarding rate 74.4 Mpps
Switching buffer 12 Mbit
MAC address table 16K
Input voltage 100 - 240V AC 50/60Hz
Dimensions 440 mm * 240 mm * 44 mm(L x W x H)
Environment Operating temperature: 0°C - 45°C
Operating humidity: (10% - 90%)RH, non-condensing
Storage temperature: -40°C - 70°C
Storage humidity: (5% - 90%)RH, non-condensing
Certificates CCC, FCC, CE, RoHS
Software features
Security features Support ARP receiving limit
Support discarding unknown MAC addresses
Support DoS attack defense
Support 802.1x security authentication
Support RADIUS authentication
VLAN Support 4 K VLAN table
Support IEEE 802.1q VLAN
Support three port modes: Access, Trunk and Hybrid
DHCP Support DHCP snooping
Support Option 82 policy configuration
Port aggregation Support Static aggregation
Support Dynamic aggregation
STP Support IEEE 802.1d STP (Spanning Tree Protocol)
Support IEEE 802.1w RSTP (Rapid Spanning Tree Protocol)
Support IEEE 802.1s MSTP (Multiple Spanning Tree Protocol)
Support edge ports
Support BPDU statistics
IGMP Support IGMP snooping V1/V2/V3
Support fast leave of ports
Port mirroring Support N: 1 port mirroring
QoS Support SP (Strict Priority)
Support SWRR (Simple Weighted Round Robin)
Support WRR (Weighted Round Robin)
Support 802.1p port trust mode
Support DSCP port trust mode
Support a maximum of 8-queue service quality mapping
ACL Support MAC ACL
Support IPv4 ACL
Cloud Management Support configuration delivery from CloudFi management platform
Support CloudFi App management
Support log reporting and fault detection
Support remote maintenance: reboot, backup, upgrade
Local Visualization Support discovery of such network devices as routers, switches, APs based on LLDP
Support IP camera discovery based on ONVIF protocol
Support automatic generation of topology
Support local view and main view
Support online/offline status detection for devices
Support remote IP cameras reboot
Support loop alert
Support custom device types and device names
Loading and upgrade Support HTTP upgrade
Support Configuration import and export
Management and maintenance Support Telnet configuration
Support SNMP V1/V2/V3
Support web management and maintenance
Support system log
Support log classification
Support NTP
Support Ping and Tracert tests
Support memory and CPU monitoring
